This outdoor display meets the industrial IP65 waterproof and dustproof rated, equipped with international standard VESA holes for various installations, ideal for advertising in any outdoor scene. The screen brightness up to 3500 nits, and the built-in intelligent light sensor ensures a clear and bright display 24/7. Additionally, the optional capacitive touch providing interactive method for customers. The metal casing is available in black and white, according to your needs.
Optional Panel Size:
15 inch-86 inch
Model No | RCS-150ODC | RCS-156ODC | RCS-185ODC | RCS-191ODC | RCS-220ODC | RCS-240ODC | RCS-270ODC | RCS-320ODC | RCS-430ODC | RCS-490ODC | RCS-550ODC | RCS-650ODC | RCS-750ODC | RCS-860ODC |
Max Resolution | 1024×768 | 1920×1080 | 1366×768 | 1440×900 | 1920×1080 | 1920×1080 | 1920×1080 | 1920×1080 | 1920×1080 | 1920×1080 | 1920×1080 | 3840×2160 | 3840×2160 | 3840×2160 |
Aspect Ratio | 4:3 | 16:10 | 16:9 | 16:10 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 | 16:9 |
Pixel Pitch | 0.297×0.297 | 0.17925×0.17925 | 0.300×0.300 | 0.2835×0.2835 | 0.24795×0.24795 | 0.2745×0.2745 | 0.31125×0.31125 | 0.36375×0.36375 | 0.4903×0.4903 | 0.27963x0.27963 | 0.63×0.63 | 0.372×0.372 | 0.429×0.429 | 0.4935×0.4935 |
Viewing Angle | 80/80/65/80 | 85/85/85/85 | 89/89/89/89 | 85/85/80/80 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 |
Contrast Ratio | 800:1 | 700:1 | 1000:1 | 1000:1 | 1000:1 | 1000:1 | 1000:1 | 1400:1 | 1200:1 | 1200:1 | 1400:1 | 1400:1 | 1200:1 | 1200:1 |
Brightness (cd/m²) | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 | 2000-3500 |
Display Area (mm) | 304.128x228.096 | 344.16×193.59 | 409.8×230.4 | 408.24×255.15 | 476.064×267.786 | 527.04×296.46 | 597.888×336.312 | 698.4×392.85 | 941.184×529.416 | 1073.78×604 | 1209.6×680.4 | 1428.48×803.52 | 1649.66×927.936 | 1895.04×1065.96 |
Panel Size (mm) | 326.5×253.5×9.6 | 359.5×223.8×3.2 | 430.4×254.6×7.8 | 428×278×11 | 495.6×292.2×10.7 | 543×317.4×11.6 | 630×368.2×11.8 | 725.2×422.7×22.4 | 969×563.9×26 | 109.5×62.9×29.6 | 1244.6×720.9×27 | 1459.2×830×16 | 1675.2×953.6×11.9 | 1922.2×1093.2×16.14 |
